与自然对话：LLM 住宅

公司：	OBRA Arquitetos LTDA	类型：	建筑 \| 景观
地区：	巴西	标签：	庭院花园 \| 别墅私宅

坐落在一个拥有大量本土树木和平均坡度30%的场地上，该项目是现代建筑与自然的一次对话。

Situated on a site with a large number of native trees to be preserved and average slope of 30%, the implementation of the project suggests an intense dialogue with the existing to pography and vegetation.

考虑到建筑面积为1185,00平方米，我们试图使人们能够在不同的环境和水平的房子里进行直接的交流。因此空间内的障碍应该极度减小，以为了屋主及家人提供一个开放的交流空间。

Considering the built area of 1185,00m², suggested by the customer and necessary to resolve the entire program, we tried to develop a project where people could have direct eye contact, despite being in different environments and levels of the house. This prevents the isolation and facilitate meetings of its residents with greater objectivity.

项目也正是这样设计的：集体空间，生活空间，工作空间和烹饪空间都充满阳光，并且有很好的景观视野。房间和更私密的环境被放置在树梢下，形成了一个有树干的庭院。钢筋混凝土挡土墙和两个山墙伫立在地面上，用于锚定在挂在树上的金属框架上。

The program was arranged so that the collective spaces, being, working and cooking, have a relationship with the larger landscape views and higher light intensity. The rooms and more intimate settings were positioned below the treetops, forming a courtyard with tree trunks. The house was designed in mixed structure. Retaining walls in reinforced concrete and 2 gables also specifically serve for adjustment of some quotas of the land and anchoring to the metal frame, hoisted on the trees.

房间跨度24米，有两个1.50米的金属梁。其中一根横梁支撑着悬挂的夹层。在对梁的自重和荷载进行结构分析后，我们考虑了这一方案，梁的荷载远高于夹层的荷载要求。

The room has a span of 24 meters, won with two metal beams with 1.50m . One of these beams support the suspended mezzanine. This alternative was considered after the structural analysis of the own weight and loading the beams were much higher than the load request from the mezzanine.
